ANDREOLI ENGINEERING
Operator’s Manual
Self-propelled sprayer ATOM
3.12 AIR CONDITIONING AND HEATING SYSTEM
3.12.1 Manual A/C controls
1) ON/OFF fan + Fan speed selection
2) ON/OFF A/C compressor
3) ON/OFF heating – manual tap
Use knob (2) to activate A/C compressor.
When the compressor is on, the A/C lamp on main instrument will light on.
When the set temperature in the evaporator is reached, the compressor will turn off and the A/C lamp will
turn off.
The temperature is set by the A/C thermostat.
3.12.2 A/C thermostat
Thermostat controls the functionality of A/C system.
The following drawing shows how to set the position of the thermostat:
