3.6 ACCESS TO TOP OF TANK - STEP
The machine is equipped with a sliding step, to access the top of the tank.
1) Step
2) Step lock
Turn the lock 90°.
Pull the step out.
Do NOT run the machine with the step out.
Remember to always close the step and secure it with the lock, before running the machine.
1
2
1
