ANDREOLI ENGINEERING
Operator’s Manual
Self-propelled sprayer ATOM
7.15 CAB AIR FILTER
The cab air filter is located inside a housing:
1) Air carbon filter
2) Housing
3) Filter cover
To replace the cab air filter:
Remove top cover (3)
Lift the filter (1) and remove it from the housing (2)
The following drawing shows the carbon filter:
On the filter body there is an arrow which indicates the direction of airflow through the filter.
When replacing the filter make sure to place it in the right position according to the direction of
airflow.
Airflow must pass through the filter only in one way, as indicated by the arrows on the filter frame.
