ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
89/166
4.2.9 Parking the machine – mechanical brake
When parking the machine the following operations are necessary:
 Put main joystick to neutral position (central position);
 set the throttle to the minimum
 disengage all clutches (chemicals pump and fan);
 keep engaged the mechanical gear, do not put the Hi/Low lever to neutral position;
 engage the parking brake: use the parking brake lever.
It is necessary to stop on a flat protected area, to avoid stresses on the brakes.
Keep far from the machine non authorized people.
4.2.10 Differential lock
If the machine is equipped with differential lock, pay attention to lock only when the wheels are straight.
When the differential is locked, steer the wheels at max 5-8° from the straight direction, to
avoid damages to the axle.
To lock push the switch, to unlock push the switch and brake some times using the emergency pedal to help
the unlock.
