When the Hi/Low lever is neutral position, the machine can move free.
DO NOT leave the machine with the Hi/Low lever in neutral position without parking brake
engaged.
DO NOT move the Hi/Low lever when the machine is moving.
Before moving the Hi/Low lever, make sure the main joystick is in neutral position.
When moving the Hi/Low lever from neutral position into I or II gear, it is possible to move the
main joystick for 1 second and then put it again into neutral; this will make the hydraulic motor
and gears turning for a while, helping the new gear to find its position easily.
3.11.6 Command box of switches
Machine can be equipped with a command box of switches, to control nozzles sections independently:
1) Nozzles section ON/OFF
2) Main ON/OFF for left side and right side (controls sections 1+2 and 3+4)
3) Main ON/OFF for all sections (sections 1+2+3+4)
4) Pressure regulation
When the command box is installed, main joystick has no switches to control nozzles sections.
When the command box is installed, spray pressure can be adjusted using the switch on the
command box.
The standard pressure regulation switch on the steer column is disabled.
