ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
72/166
3.13.9 Hand washing tank
The machine is equipped with a hand-washing tank to wash hands in case of contamination.
Remember to fill up the hand-washing tank before starting any spraying operation.
3.13.10 Filters
Chemicals circuit is equipped with suction filter and pressure filters.
Standard chemicals circuit:
1) Suction filter
2) Pressure filter for tank mixture agitators
3) Pressure filter for valves
4) 3-way valve
3
1
2
4
