3.3 DRIVELINE
1) Front axle
2) Rear axle
3) Cardan shaft
4) Gear box Hi/Low (I / II)
5) Hydraulic motor (Rabbit / Turtle)
1) Main hydraulic pump
2) Fan clutch and support case
3) Blower fan
4) A/C compressor
5) Main cooler
4
5
1
2
3
2
1
3
4
5
