ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
149/166
7.20 ELECTRICS
Before changing fuses turn off the engine and remove the ignition key.
All fuses must be replaced once solved the cause of malfunction.
7.20.1 Main fuses box
Main box for fuses and relays is placed inside the cab, on the right side:
1) Fuses/Relays box
2) Automatic AC controller Relays box (optional)
7.20.2 R754IE4 / R754TE4 fuses box
1
2
