ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
53/166
3.11.5 Levers
Main Joystick
A) Forward direction
B) Reverse direction
C) Stop
Main joystick has a safety lock in stop position (C). To move the joystick from the stop position, incline it to
the left side and then push/pull.
1) Main Joystick Forward/Reverse
2) Throttle
3) Mechanical Hi/Low gear
A
B
C
1
2
3
