ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
66/166
3.13.3 Chemicals tank – disinfection
1) Main tank for chemicals
2) Tank lid
3) Nominal tank level indicator
4) Suction
5) Drain
To empty the tank open the ball valves placed under the tank on the two sides:
1) Drain ball valve
2) Suction
3) Low pressure drain line for agitators
A) Open
B) Closed
It is absolutely forbidden entering the tank.
1
2
A
B
3
2
2
3
1
4
5
