ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
61/166
Clean the A/C condenser at least once a week with compressed air.
Cleaning frequency depends on working conditions.
Before the spraying season check charge of A/C csystem with the proper gas:
R134a (HFC-134a) - CH2FCF3
3.12.6 A/C Filter
A/C filter is located on the right side of the machine:
1) A/C filter
3.12.7 A/C evaporator
The following drwaing shows the location of A/C evaporator:
1) A/C Evaporator + Heating section
1
1
