DESCRIPTION OF THE RELAYS
Nr
Function
E1
Sprayer fan clutch
E2
Chemicals pump clutch
E3
Clucthes enable
E4
Dump valve
E5
A/C fans
E6
High beam
E7
Low beam
E8
Sprayer fan clutch enable
E9
Chemicals pump clutch enable
E10
Dump valve
I1
Flashers
DESCRIPTIONS OF THE FUSES
Nr
Ampere
Description
Function
1
20
+15 Services
Sprayer fan clutch
2
15
+15 Services
Joystick
Pressure regulator
3
10
+15 Services
Steer mode selection
Dump valve
4
10
+15 Services
Radio
5
15
+15 Services
Pneumatic seat
6
3
+15 Services
Emergency stop button
7
15
+15 Services
Work lights rear
Work light engine vane
8
5
+15 Services
Alarms buzzer
Sensors
Main instrument
Diagnostic
9
10
+15 Services
Chemicals pump clutch
10
7.5
+15 Services
Micro stop lights
Micro reverse
11
7.5
+15 Services
Rotating light
12
7.5
+15 Services
Warning lights switch
Inside cab light
13
20
+15 Services
A/C fan in the cab
14
7.5
+15 Services
Hydraulic park brake switch
Hi/Low hydraulic switch
15
20
+15 Services
Chemicals pump clutch
16
15
+15 Services
Work lights front
17
15
+15 Services
Work lights rear
18
20
+15 Services
A/C condenser fans
19
10
+15 Services
A/C compressor
20
15
+15 Services
Automatic spray rates controller
21
15
+30 Battery
High beam
22
3
+15 Services
Position lights
23
3
+15 Services
Position lights
24
15
+30 Battery
Low beam
25
7.5
+15 Services
Clacson
