ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
152/166
DESCRIPTIONS OF THE FUSES
Nr
Ampere
Description
Function
1
20
+15 Services
Sprayer fan clutch
2
15
+15 Services
Joystick
Pressure regulator
3
10
+15 Services
Steer mode selection
Dump valve
4
15
+15 Services
Radio
Automatic spray rates controller
5
15
+15 Services
Sensors
Display (Level + Pressure)
6
10
+15 Services
Emergency stop button
7
15
+15 Services
Work lights rear
Work light engine vane
8
10
+15 Services
Alarms buzzer
Main instrument
9
10
+15 Services
Chemicals pump clutch
10
5
+15 Services
Micro stop lights
Micro reverse
11
15
+15 Services
Clacson
Rotating light
12
15
+15 Services
Warning lights switch
Pneumatic seat
13
20
+15 Services
A/C fan in the cab
14
7.5
+15 Services
Hydraulic park brake switch
Hi/Low hydraulic switch
15
20
+15 Services
Chemicals pump clutch
16
15
+15 Services
Work lights front
17
15
+15 Services
Work lights rear
18
20
+15 Services
A/C condenser fans
19
10
+15 Services
A/C compressor
20
15
+15 Services
Engine stop solenoid
21
15
+30 Battery
High beam
22
7.5
+15 Services
Position lights
23
7.5
+15 Services
Position lights
24
10
+30 Battery
Low beam
25
5
+15 Services
Inside cab light
26
15
+15 Services
Windscreen wiper
Windscreen washing pump
27
10
+15 Services
Warning lights
28
15
+30 Battery
+15 Services
Radio
Lighter
