Andreoli Engineering ATOM 1000 - Page 155

ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
155/166
DESCRIPTIONS OF THE FUSES
Nr
Ampere
Description
Function
X201.1
1
20
+15 Services
Sprayer fan clutch
2
15
+15 Services
Pressure regulator
3
10
+15 Services
Steer mode selection
Dump valve
4
15
+15 Services
Radio
Automatic spray rates controller
5
15
+15 Services
F5
6
10
+15 Services
Emergency stop button
7
15
+15 Services
Work lights rear
Work light engine vane
8
10
+15 Services
F8
9
10
+15 Services
Chemicals pump clutch
10
5
+15 Services
Micro stop lights
Micro reverse
11
15
+15 Services
Clacson
Rotating light
12
15
+15 Services
Warning lights switch
Pneumatic seat
13
20
+15 Services
Fuse optional
14
7.5
+15 Services
Fuse optional
15
20
+15 Services
Fuse optional
16
15
+15 Services
Fuse optional
X201.2
1
10
+30 Battery
Emergency
2
15
+30 Battery
Radio
Lighter
3
20
+15 Services
Chemicals pump clutch
4
15
+15 Services
Work lights front
5
15
+30 Battery
Work lights
6
3
+15 Services
A/C automatic system
7
10
+15 Services
A/C compressor
8
15
+30 Battery
Engine stop
9
5
+15 Services
Inside cab light
10
15
+15 Services
Windscreen wiper
Windscreen washing pump
11
7.5
+15 Services
Hydraulic park brake switch
Hi/Low hydraulic switch
12
20
A/C fan in the cab
13
15
High beam
14
7,5
Position lights
15
7,5
Position lights
16
10
Low beam
