ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
157/166
DESCRIPTION OF THE RELAYS
Nr
Function
X229 – X230
Main power relay
X343
A/C compressor
X234
Main engine VM
X228
Engine starting
X224
Engine warm-up
X223
Fuel filter pre-heater
DESCRIPTION OF THE FUSES
Nr
Ampere
Description
Function
F1
20
+30
Fuel filter pre-heater
F2
50
+30
Main power relay
F3
20
+30
Steer column
F4
30
+30
Engine starting
F5
60
+30
Engine warm-up
X232
15
+15
Engine ECU
X233
15
+15
Engine sensors
X235
10
+15
Engine ECU
