ANDREOLI ENGINEERING Operator’s Manual
Self-propelled sprayer ATOM
9/166
ATOM 2000 R754IE4 WIDE
DIMENSIONS
Length
5590
mm
Width
1830 / 1980
mm
Height
1400 / 1510
mm
ENGINE
Max power
80
kW
ATOM 2000 D754IE3 WIDE
DIMENSIONS
Length
5590
mm
Width
1830 / 1980
mm
Height
1400 / 1510
mm
ENGINE
Max power
70
kW
NOISE / VIBRATIONS
Acoustic pressure LPA
84.3 ± 1.0
dBA
According to
UNI EN ISO 4254-1
Acoustic power LWA
115.4 ± 0.9
dBA
According to
UNI EN ISO 4254-1
Vibrations at the body
0.95 ± 0.05
m/s²
According to
UNI EN 1032
Vibrations at steering wheel
2.2 ± 0.1
m/s²
According to
UNI EN 1032
CHEMICALS CIRCUIT
Max pressure
50
bar
Max flow:
IDS 1201
125
l/min
IDS 1701
160
l/min
IDS 2001
180
l/min
IDS 2200
220
l/min
PPS 1615
147
l/min
