11-23
11.4 Description of Measuring Instrument Driver Functions
MS9710A Graph ;Graph Clear
MS9710
Graph
Clear
This driver clears the displayed graph.
MS9710A Graph ;Set Display Mode
MS9710
Disp
Mode
This driver sets a display mode.
Input parameters:
Display Mode (Normal: 0) ......... Select a display mode.
0. Normal.................................. Set a normal display mode.
1. Over Lap............................... Set an overlap display mode.
2. Max Hold ............................. Set a max. hold display mode.
3. Normalize ............................. Set a normalize display mode.
4. 3D ......................................... Set a 3-dimensional display mode.
3D Type (Type1: 1) .................... Set a 3-dimensional display mode type (1,2, or 3).
(Effective only when the display mode is 3D.)
3D Angle (degree) (45 degree: 1) ... Set a 3-dimensional display angle (30, 45, 60, or 90 degrees).
(Effective only when the display mode is 3D. When the 3D Type is set to 3, only
45 may be set.)
MS9710A LevelScale ;Log/Linear
MS9710
Log/Lin
This driver switches between log and linear scales and sets a scale value.
Input parameters:
Log/Linear (Log: F).................... Select a log or linear scale.
Scale Value (no change) ............. Set a scale value.
When no value is input, the previous setting is used.
Output parameter:
Scale Value · Suffix .................... Outputs a scale value and unit.
MS9710A LevelScale ;Opt.Att Off/On
MS9710
Opt.Att
This driver turns on/off the internal attenuator.
Input parameter:
Off/On (Off: F) ........................... Turn on/off the attenuator.
