Section 11 LabVIEW Measuring Instrument
11-24
MS9710A LevelScale ;Ref Level
MS9710
Ref Lvl
This driver sets a reference level when a log scale is selected.
Input parameter:
Ref Level (dBm,dB) (no change) ... Set a reference level.
Output parameter:
Reference Level .......................... Outputs a reference level.
MS9710A Marker ;Delta Marker
MS9710
∆ Mkr
This driver sets a delta marker and outputs the differences in wavelength and level between the delta marker and the
trace marker.
Input parameter:
Wavelength (nm) or (THz) ......... Set a wavelength of the delta marker.
When no value is input, the previous setting is used. (This parameter
must not be omitted when no delta marker is displayed.)
Output parameters:
Delta Wavelength (nm) or (THz) ... Outputs the difference in wavelength between the delta marker and trace marker.
Delta Level ................................. Outputs the difference in level between the delta marker and the trace marker.
If analysis is impossible, –1 is output. (Effective only when the linear scale is
selected.)
MS9710A Marker ;Lvl Marker
MS9710
LMkr
This driver sets a level marker and marker values (level and unit).
Input parameters:
MarkerC/D (C: False) ................. Select marker C or D.
Level (no change) · Suffix(dBm: 0)
.............................................. When no value is input, the previous setting is used. (This parameter must not be
omitted when no level marker is displayed.)
Output parameter:
Level · Suffix .............................. Output a marker level and unit.
