11-25
11.4 Description of Measuring Instrument Driver Functions
MS9710A Marker ;Marker Erase
MS9710
OffMkr
This driver erases all markers other than zone markers.
MS9710A Marker ;Trace Marke
MS9710
TMkr
This driver sets a trace marker and outputs marker values (wavelength, level, and unit).
Input parameter:
Wavelength (nm) or (THz) ......... Set a trace marker wavelength.
When no value is input, the previous setting is used. (This parameter must not be
omitted when no trace marker is displayed.)
Output parameters:
Wavelength (nm) or (THz) ......... Outputs a trace marker wavelength.
Level · Suffix .............................. Outputs a trace marker level and unit.
MS9710A Marker ;Wl Marker
MS9710
λMkr
This driver sets a wavelength marker and outputs marker wavelength.
Input parameters:
MarkerA/B (A: False) ................ Select marker A or B.
Wavelength (nm) or (THz) ......... Set a marker wavelength.
When no value is input, the previous setting is used. (This parameter must not be
omitted when no wavelength marker is displayed.)
Output parameter:
Wavelength (nm) or (THz) ......... Outputs a marker wavelength.
MS9710A MeasurMode ;D.Range Norm/High
MS9710
Norm/Hi
This driver selects a normal or high dynamic range.
Input parameter:
Normal/High (Normal: F) .......... Set a normal or high dynamic range.
