11-27
MS9710A MeasurMode ;Power Monitor
MS9710
Pow.M
This driver sets power monitor measurement and outputs a power monitor measurement value.
The VI terminates when a power monitor value is read.
To terminate power monitor measurement, execute “Measure Mode Off.vi”.
Input parameter:
Wl Range (nm) (no change) ....... Set a wavelength range (632.8/850.0/1300.0/1550.0 nm).
When no value is input, the previous setting is used.
Output parameter:
Power (dBm) .............................. Outputs a power monitor measurement value.
MS9710 Others ;Buzzer Off/On
MS9710
Buzzer
This turns the buzzer ON or OFF.
Input parameter:
Off/On (Off: F) ........................... Selects On or Off
MS9710A Others ;Back Light
MS9710
Back
Light
This driver sets a backlight off time.
Input parameter:
BackLight Time (min) (10) ........ Set a backlight off time.
If 0 is input, the backlight will not turn off.
MS9710A Peak/Dip ;Peak/DipSearch(1)
MS9710
1
Psearch
This driver moves the trace marker to the peak or dip and output a trace marker wavelength and level.
When processing is complete, the VI is terminated.
Input parameter:
Peak/DipSearch (Peak: F) .......... Peak/Dip Search (Peak: F): Select peak or dip search.
Output parameters:
Wavelength (nm) ........................ Outputs a trace marker wavelength.
When no peak or dip is detected, –1 is output.
Level Suffix ................................ Outputs a trace marker level and unit.
When no peak or dip is detected, –999.99 is output.
When a trace marker level cannot be obtained, –1 is output (linear scale only).
11.4 Description of Measuring Instrument Driver Functions
