Section 11 LabVIEW Measuring Instrument
11-28
MS9710A Peak/Dip ;Peak/DipSearch(2)
MS9710
2
Psearch
This driver detects a peak or dip set by Search Mode among the peaks and dips detected by Peak/DipSearch(1), and
moves the trace marker there.
When Peak/DipSearch has not been executed, PeakSearch is executed.
When processing is complete, the VI is terminated.
Input parameter:
Search Mode (Next: 0) ............... Set a search mode (Next, Last, Left, Right).
Output parameters:
Wavelength(nm) ......................... Outputs a trace marker wavelength.
When no peak or dip is detected, –1 is output.
Level Suffix ................................ Outputs a trace marker level and unit.
When no peak or dip is detected, –999.99 is output.
If a trace marker level cannot be obtained, –1 is output (linear scale only).
MS9710A Res/BW/Avg ;Actual Resolution
MS9710
Act-Res
This driver turns off actual resolution display and outputs an actual resolution value.
Input parameter:
Off/On (Off: F) ........................... Turn on/off actual resolution display.
Output parameter:
Actual Resolution value (nm)..... Outputs an actual resolution value.
MS9710A Res/BW/Avg ;Average
MS9710
Avg
Sets or cancels point average processing, sweep average processing, and smoothing processing.
Input parameters:
Average Times (Off: 0) .............. Sets a number of point average processing points or a sweep average processing
count.
Point/Sweep (Point: F) ............... Select point or sweep average.
Smooth Points (Off: 0) ............... Set a number of smoothing points (3, 5, 7, 9, or 11).
When no value is input, smoothing processing is canceled.
