11-29
11.4 Description of Measuring Instrument Driver Functions
MS9710A Res/BW/Avg ;Res/BW/SmplPt
MS9710
Res/BW
SmplPt
This driver sets measurement resolution, video bandwidth, and number of sampling points in span.
When no value is input, the previous setting is used.
Input parameters:
Sampling Points (no change)...... Set a number of sampling points in span.
Resolution (nm) (no change) ...... Set measurement resolution.
Video Band Width (no change) .. Set a video bandwidth.
Output parameters:
Sampling Points .......................... Outputs a number of sampling points in span.
Resolution (nm) .......................... Outputs measurement resolution.
Video Band Width (Hz) ............. Outputs a video bandwidth.
MS9710A Save/Recall ;FD
MS9710
FD
This driver saves data, recalls data, deletes data, or formats the FD.
When saving, recalling, deletion, or formatting is complete, the VI is terminated.
Input parameters:
Mode (Save: 0) ........................... Select data saving, data recalling, data deletion, or FD formatting.
Data Addition (no change) ......... Determine whether bit-map-format data and text-format data are to be saved
in addition to the basic-format data.
When no value is input, the previous setting is used.
File Name (“ ”) .......................... Input a file name.
timeout (ms) (600000) ................ Set a timeout time.
MS9710A Title
MS9710
Title
This driver inputs a title to be displayed on the screen.
Input parameter:
Title (“ ”) ................................... Set a title to be displayed on the screen (max. 30 characters).
