Anritsu MT8802A - LCD Disassembly Diagram (Part 3)

9-9
Section 9 Mechanical Configuration
Fig. 9-7 LCD Disassembly (3/3)
[22] LTM08C015KA Z5 LCD
[23] INVC193 Z6 LCD INVERTER
[49] 332B37694 Cover
[59] 332B37683 Bracket 1 (for LCD Inverter)
[50] 332B37684 Bracket 2 (for LCD)
[26] 322U13222 A07 PANEL CONTROL
