144 Camera preparation
Step 2: Mounting the BAP-4 to the MAP-2
1
2
3
1. Place the BAP-4 (2) exactly above the mounting points (3) of the MAP-2 (2).
2. With a flat screwdriver, attach the screws (1) to the MAP-2 and tighten.
NOTICE
Always use a flat screwdriver to connect the BAP-4 to the MAP-2. Never use a
coin. A coin does not deliver enough force to ensure a proper lock.
