Camera preparation 145
Step 3: Mounting the BP-8 to the BAP-4
1
2
3
1. Place the BP-8 (2) exactly above the mounting points (3) of the BAP-4 (2).
2. With a flat screwdriver, attach the screws (1) to the BAP-4 and tighten.
NOTICE
Always use a flat screwdriver to connect the BP-8 to the BAP-4. Never use a
coin. A coin does not deliver enough force to ensure a proper lock.
