ARRI ALEXA Mini - Page 152

152 Assembly and retrofits
1
2
1. Properly align the two guiding pins (1) for correct lens mount fit (2).
Note: Never apply force, align the guiding pins instead.
1
1
2. Crosswise, hand-tighten all four screws (1).
3. Only then, tighten all screws crosswise with the Allen key.
Note: Always store the camera with a lens mount properly installed and capped.
