Technical Data are subject to change without notice.CAMERA DIMENSIONS – Version 2015-08
ALEXA Mini
ALEXA Mini Length Width Height Weight
ALEXA Mini (camera body with titanium PL lens mount) 184.75 mm - 7.27” 124.83 mm - 4.91” 140 mm - 5.5” ~ 2.3 kg/5 lbs
Camera Right
Image Plane
Camera Front
Optical Center
Optical Center
140 mm
5.5”
23.2 mm
0.91”
27.8 mm
1.09”
70 mm
2.75”
70 mm
2.75”
62.42 mm
2.45”
62.42 mm
2.45”
124.83 mm
4.91”
127.65 mm
5.03”
Ø 48.05 mm
Ø 1.89”
Ø 48.05 mm
Ø 1.89”
57.1 mm
2.25”
42.16 mm
1.66”
