Digital Video Recorder
9
DISPLAY/SPOT Button
Pressing the DISPLAY/SPOT button toggles between different display formats. The available formats
are: PIP, 2x2, 3x3 and 4x4.
Pressing and holding the button for two seconds or longer allows you to select which cameras will display
on the Spot monitor.
GROUP/SEQUENCE Button
When in the live mode, pressing the GROUP/SEQUENCE button changes the screen from the current
camera group to the next camera group, and the screen displays the page number. Pressing and holding
the button for two seconds or longer displays live channels sequentially.
PLAYBACK Button
Pressing the PLAYBACK button enters the playback mode, and pressing the button again exits the
playback mode. When entering the playback mode, video is paused. Pressing the (Play/Pause) button
plays back video at regular speed. The screen displays
when the DVR is in the Pause mode and the
screen displays when the DVR is playing back video.
MENU/CAMEO Button
Pressing the MENU/CAMEO button enters the Setup screen. You will need to enter the authorized user
and password to access Setup. Pressing the button also closes the current menu or setup dialog box. In
the Playback mode, pressing the button displays the Search menu.
Pressing and holding the button for two seconds or longer enters the cameo mode. The yellow outline
surrounding the video indicates the active cameo, and pressing the arrow buttons moves the active cameo.
Pressing the desired camera button in the active cameo edits the cameo and displays the video of selected
camera. Pressing the
(Play/Pause) button exits the Active Cameo mode. Selecting Exit Group Edit in
the cameo menu displayed when pressing the MENU/CAMEO button also exits the Active Cameo mode.
NOTE: A cameo is defined as any cell within multi-screen display. The cameo mode allows you to
change the screen layout by editing the cameo.
Arrow Buttons
These buttons are used to navigate through menus and GUI. You can also use them to change numbers by
highlighting a number in the menu and using the Up and Down arrow buttons to increase or decrease the
number’s value.
These buttons are also used to control Pan and Tilt when in the PTZ mode. When in the PIP display
format, pressing the Up and Down arrow buttons moves the position of the small screen
counter-clockwise and clockwise, and pressing the Left and Right buttons changes the PIP screen size.
In the playback mode, pressing the button plays video backward at high speed. Pressing the button
again toggles the playback speed from
, and . The screen displays , and
respectively. Pressing the
button plays video forward at high speed. Pressing the button again toggles
the playback speed from
, and . The screen displays , and
respectively. When
in the pause mode, pressing the
button moves to the next image and pressing the button moves to the
previous image.
