Digital Video Recorder
69
Highlight the box beside Type and press the button. You can select between Motion Search and
Museum Search. Motion Search detects motion in the defined area. Museum Search detects if a
defined object has moved.
Highlight the box beside Zone and press the
button. An image from the video appears with a grid
overlaid. You can turn sensor blocks On and Off to define the area of the picture in which you want to
search for motion.
NOTE: Defining the area of the image in which you want to search for motion is nearly identical to
setting up the DVR for Motion Detection. Please refer to Motion Detection Screen in Chapter 3 ā
Configuration for more detailed instructions on setting up the detection blocks.
NOTE: When setting the Museum Search Zone, the zone should be placed inside of the border
line of the target object. If the selected block is placed on the boarder line, the sensitivity of the
Museum Search may decrease.
The zone should be placed or focused on the centre or, at least, within the outline of targeted object.
Highlight the box beside Sensitivity and press the
button. You will be able to select from 1 (low
sensitivity) to 5 (high sensitivity).
Highlight the box beside Min. Blocks and press the
button. You will be able to set the number of
sensor blocks that must be activated. Setting the Min Blocks will only be available if Motion Search is
selected.
Once you set your desired search conditions, highlight Search and press the
button to display the
search results in the Motion Search screen. Selecting Cancel exits the screen without saving the
changes.
When you search for motion events of another camera, you will be asked whether or not you want to
delete the previous search results from the list.
Clip-Copy Screen
The Clip-Copy screen can be used to copy video clips to an internal CD-RW or DVD RW drive, or
external USB hard disk, CD-RW or flash drive. The copied video clips can be viewed on computers
running Microsoft Windows 98, ME, 2000, XP or Vista. Refer to the Appendix A ā USB Hard Disk
Drive Preparation for information on preparing the external drive for clip copy. The clip copy can be
simply done by pressing the
CLIP COPY button.
Press the
CLIP COPY button while in the Live monitoring mode, and the Clip-Copy screen appears to
allow clip copy setup.
Pressing the
CLIP COPY button during the playback will set the starting point of the video to be clip
copied, and the
icon displays at the bottom-left corner of the screen. Pressing the
CLIP COPY button
again will set the ending point of the video to be clip copied by displaying the Clip-Copy screen.
Pressing and holding the
CLIP COPY button for more than two seconds while in the Playback mode or
Live Monitoring mode initiates the One-Touch Clip Copy function. The last recorded image will be the
ending point of video to be clip copied, and the system will automatically begin to calculate the possible
video data size that the selected storage media can handle.
