ATV Falcon - Appendix I ─ Specifications

User’s Manual
82
Appendix I ─ Specifications
VIDEO
Signal Format NTSC or PAL (Auto Detect)
Video Input Composite: 8 or 16 looping inputs, 1 Vp-p, auto-terminating, 75 Ohms
Monitor Outputs
Composite: 1 BNC, 1 Vp-p, 75 Ohms
SPOT: 1 BNC, 1 Vp-p, 75 Ohms
VGA: 1
Video Resolution
Composite: 720x480 (NTSC), 720x576 (PAL)
VGA: 800x600 @ 60Hz
Playback/Record Speed
(images per second)
120/120ips (NTSC), 100/100ips (PAL)
INPUTS/OUTPUTS
Alarm Input 8 or 16 TTL, programmable as NC or NO, 4.3V threshold
Alarm Output
2 relay outputs, terminal blocks, programmable as NC or NO,
0.5A@125VAC, 1A@30VDC
Alarm Reset Input 1 TTL, terminal block
Internal Buzzer 80dB at 10cm
Network Connectivity 10/100 Mbps Ethernet (RJ-45), RS232C for external modem
Audio Input RCA Input: 2, Line In
Audio Output RCA Output: 1, Line Out
Text Input POS Interface, ATM Interface
CONNECTORS
Video Input Composite: 8 or 16 BNC
Video Loop Composite: 8 or 16 BNC (Auto Terminating)
Monitor Output
Composite: 1 BNC
VGA: 1 VGA
SPOT (Composite): 1 BNC
Audio In 2 RCA connector
Audio Out 1 RCA connector
Alarm Input/Output Terminal blocks
Ethernet Port RJ-45
RS232C Serial Port DB9 (P)
RS485 Serial Port Two-connector terminal block
USB Port 2 (USB 2.0)
STORAGE
Primary Storage
SATA hard disk drive (up to 4) (up to 3 with an internal CD-RW drive
or DVD RW)
Secondary Storage*
Built-in CD-RW drive
USB hard disk drive, CD-RW drive or flash drive
* When installing an internal CD-RW drive or DVD RW drive, connect the S-ATA I/O cable to the SATA3 socket.
Specifications are subject to change without notice.
