AudioCodes MP-124 User Manual

Version 5.8 119 September 2009
SIP User's Manual 3. Web-Based Management
¾ To configure the keypad features
1. Open the 'Keypad Features' page (Configuration tab > Protocol Configuration
menu > SIP Advanced Parameters submenu > Keypad Features page item).
Figure 3-71: Keypad Features Page
2. Configure the keypad features as required. For a description of these parameters,
refer to “Configuration Parameters Reference” on page 213.
3. Click the Submit button to save your
changes.
4. To save the changes to the flash memory, refer to ''Saving Configuration'' on page
167.

AudioCodes MP-124 Specifications

General

Model	MP-124
Category	Gateway
Analog Ports	24 FXS
Ethernet Ports	2
Protocol Support	SIP, H.323
Fax Support	T.38, G.711 pass-through
Power Supply	100-240VAC, 50-60Hz
Operating Temperature	0°C to 40°C
Voice Codecs	G.711, G.729, G.723.1, G.726
Management	SNMP
Storage Temperature	-20°C to 70°C
Humidity	10% to 90%, non-condensing
Network Interface	10/100Base-T Ethernet
