SIP User's Manual 208 Document #: LTRT-65412
MP-11x & MP-124
9. Select the tabs arrow button, and then from the shortcut menu, choose Unit Value.
10. The 'SNMPv3 Users' table is refreshed with the values that you entered in Step 4.
11. Click the Save button; the EMS and the device are now synchronized.
5.8.4 Cloning SNMPv3 Users
According to the SNMPv3 standard, SNMPv3 users on the SNMP Agent (on the device)
cannot be added via the SNMP protocol, e.g. SNMP Manager (i.e., the EMS). Instead, new
users must be defined by User Cloning. The SNMP Manager creates a new user according
to the original user permission levels.
¾ To clone SNMPv3 Users:
1. Open the 'SNMPv3 Users' screen (Network Provisioning frame > SNMPv3 Users
tab).
2. Select the user with which you wish to clone permission levels.
3. Click the
button; the 'New SNMPv3 User' window appears.
4. Provide a new user name, old passwords of the user you clone permissions from and
new user passwords.
5. Select a User permission group.
6. If the new user wishes to receive traps to the user-defined destination, select the Use
SNMPv3 User Security Profile for Trap Forwarding option to provision Trap
destination IP and Port. EMS adds this new user to the SNMP Trap Managers Table. It
is also possible to define an additional trap destination after a new user is defined.
