Version 5.8 235 September 2009
SIP User's Manual 6. Configuration Parameters Reference
Parameter Description
Activity Types to Report
via Activity Log Messages
[ActivityListToLog]
The Activity Log mechanism enables the device to send log messages
(to a Syslog server) for reporting certain types of Web operations
according to the below user-defined filters.
[PVC] Parameters Value Change = Changes made on-the-fly to
parameters.
[AFL] Auxiliary Files Loading = Loading of auxiliary files (e.g., via
'Certificate' page).
[DR] Device Reset = Reset of device via the 'Maintenance Actions'
page.
[FB] Flash Memory Burning = Burning of files or parameters to flash
(in 'Maintenance Actions' page).
[SWU] Device Software Update = cmp file loading via the Software
Upgrade Wizard.
[ARD] Access to Restricted Domains = Access to restricted domains,
which include the following Web pages:
9 (1) ini parameters (AdminPage)
9 (2) 'General Security Settings'
9 (3) 'Configuration File'
9 (4) 'IPSec/IKE' tables
9 (5) 'Software Upgrade Key' (N/A)
9 (6) 'Internal Firewall'
9 (7) 'Web Access List'
9 (8) 'Web User Accounts'
[NAA] Non Authorized Access = Attempt to access the Web interface
with a false or empty user name or password.
[SPC] Sensitive Parameters Value Change = Changes made to
sensitive parameters:
9 (1) IP Address
9 (2) Subnet Mask
9 (3) Default Gateway IP Address
9 (4) ActivityListToLog
For example: ActivityListToLog = 'pvc', 'afl', 'dr', 'fb', 'swu', 'ard', 'naa',
'spc'
6.3.3 Heartbeat Packet Parameters
The Heartbeat packet parameters are described in the table below. The device sends a
heartbeat packet to ensure that the far-end is passing traffic.
Table 6-16: Heartbeat Packet Parameters
Parameter Description
EMS: APS IP Address
[HeartBeatDestIP]
Destination IP address (in dotted format notation) to which the device
sends proprietary UDP 'ping' packets.
The default IP address is 0.0.0.0.
Note: For this parameter to take effect, a device reset is required.
