AudioCodes MP-124 - 6.1 Networking Parameters; 6.1.1 Ethernet Parameters

SIP User's Manual 214 Document #: LTRT-65412
MP-11x & MP-124
6.1 Networking Parameters
This subsection describes the device's networking parameters.
6.1.1 Ethernet Parameters
The Ethernet parameters are described in the table below.
Table 6-1: Ethernet Parameters
Parameter Description
EMS: Physical Configuration
[EthernetPhyConfiguration]
Defines the Ethernet connection mode type.
 [0] = 10Base-T half-duplex (Not applicable)
 [1] = 10Base-T full-duplex
 [2] = 100Base-TX half-duplex
 [3] = 100Base-TX full-duplex
 [4] = Auto-negotiate (default)
For detailed information on Ethernet interface configuration, refer to
''Ethernet Interface Configuration'' on page 449.
Not
e: For this parameter to take effect, a device reset is required.
Enable LAN Watchdog
[EnableLanWatchDog]
Determines whether the LAN Watch-Dog feature is enabled.
 [0] Disable = Disable LAN Watch-Dog (default).
 [1] Enable = Enable LAN Watch-Dog.
When LAN Watch-Dog is enabled, the device's overall
communication integrity is checked periodically. If no communication
is detected for about three minutes, the device performs a self test:
 If the self test succeeds, the problem is a logical link down (i.e.,
Ethernet cable disconnected on the switch side), and the Busy
Out mechanism is activated if enabled (i.e., parameter
EnableBusyOut is set to 1). Lifeline is activated if enabled (using
the parameter LifeLineType).
 If the self test fails, the device restarts to overcome internal fatal
communication error.
Notes:
 For this parameter to take effect, a device reset is required.
 Enable LAN Watchdog is relevant only if the Ethernet connection
is full duplex.
 LAN Watchdog is not applicable to MP-118.
