AudioCodes MP-124 User Manual

Version 5.8 57 September 2009
SIP User's Manual 3. Web-Based Management
3.2.3 Resetting an Analog Channel
The 'Home' page allows you to inactivate (reset) an FXO or FXS analog channel. This is
sometimes useful in scenarios, for example, when the device (FXO) is connected to a PBX
and the communication between the two can't be disconnected (e.g., when using reverse
polarity).
¾ To reset a channel:
 Click the required FXS or FXO port icon, and then from the shortcut menu, choose
Reset Channel; the channel is changed to inactive (i.e., the port icon is displayed in
grey).
Figure 3-34: Shortcut Menu for Resetting a Channel (e.g. MP-11x Home Page)

AudioCodes MP-124 Specifications

General

Model	MP-124
Category	Gateway
Analog Ports	24 FXS
Ethernet Ports	2
Protocol Support	SIP, H.323
Fax Support	T.38, G.711 pass-through
Power Supply	100-240VAC, 50-60Hz
Operating Temperature	0°C to 40°C
Voice Codecs	G.711, G.729, G.723.1, G.726
Management	SNMP
Storage Temperature	-20°C to 70°C
Humidity	10% to 90%, non-condensing
Network Interface	10/100Base-T Ethernet
