Page #234 background imageLoading...
Page #234 background image
SIP User's Manual 234 Document #: LTRT-65412
MP-11x & MP-124
Parameter Description
Delay After Reset [sec]
[GWAppDelayTime]
Defines the time interval (in seconds) that the device's operation is
delayed after a reset.
The valid range is 0 to 45. The default value is 7 seconds.
Note: This feature helps overcome connection problems caused by
some LAN routers or IP configuration parameters' modifications by a
DHCP server.
6.3.2 CDR and Debug Parameters
The CDR and debug parameters are described in the table below.
Table 6-15: CDR and Debug Parameters
Parameter Description
Web: CDR Server IP
Address
EMS: IP Address of CDR
Server
[CDRSyslogServerIP]
Defines the destination IP address to where CDR logs are sent.
The default value is a null string, which causes CDR messages to be
sent with all Syslog messages to the Syslog server.
Note: The CDR messages are sent to UDP port 514 (default Syslog
port).
Web/EMS: CDR Report
Level
[CDRReportLevel]
Determines whether Call Detail Records (CDR) are sent to the Syslog
server and when they are sent.
[0] None = CDRs are not used (default).
[1] End Call = CDR is sent to the Syslog server at the end of each
call.
[2] Start & End Call = CDR report is sent to Syslog at the start and
end of each call.
[3] Connect & End Call = CDR report is sent to Syslog at connection
and at the end of each call.
[4] Start & Connect & End Call = CDR report is sent to Syslog at the
start, at connection, and at the end of each call.
The CDR Syslog message complies with RFC 3161 and is identified by:
Facility = 17 (local1) and Severity = 6 (Informational).
Web/EMS: Debug Level
[GwDebugLevel]
Syslog debug logging level.
[0] 0 = Debug is disabled (default).
[1] 1 = Flow debugging is enabled.
[2] 2 = Flow and device interface debugging are enabled.
[3] 3 = Flow, device interface, and stack interface debugging are
enabled.
[4] 4 = Flow, device interface, stack interface, and session manager
debugging are enabled.
[5] 5 = Flow, device interface, stack interface, session manager, and
device interface expanded debugging are enabled.
Note: Usually set to 5 if debug traces are needed.
