SIP User's Manual 50 Document #: LTRT-65412
MP-11x & MP-124
¾ To replace the default logo with a different image using the ini file:
1. Place your corporate logo image file on the TFTP server in the same folder where the
device’s ini file is located.
2. Configure the following LogoFileName and LogoWidth ini file parameters.
For a description of these ini file parameters, refer to ''Web and Telnet Parameters'' on
page 229.
3. Load
the ini file to the device using BootP/TFTP (i.e., not through the Web interface).
For detailed information on the BootP/TFTP application, refer to the Product Reference
Manual.
3.1.8.1.2 Replacing the Corporate Logo with Text
The corporate logo can be replaced with a text string instead of an image. To replace
AudioCodes’ default logo with a text string using the ini file, configure the ini file parameters
listed in the table below. (For a description on using the ini file, refer to ''Modifying an ini
File'' on page 193.)
Table 3-2: ini File Parameters for Re
placing Logo with Text
Parameter Description
UseWebLogo
[0] = Logo image is used (default).
[1] = Text string used instead of a logo image.
WebLogoText
Text string that replaces the logo image.
The string can be up to 15 characters.
Note:
When a text string is used instead of a logo image, the Web browser’s title bar
displays the string assigned to the WebLogoText parameter.
3.1.8.2 Customizing the Product Name
You can customize the product name (text) that appears in the Title bar, using the ini file
parameters listed in the table below. (For a description on using the ini file, refer to
''Modifying an ini File'' on page 193.)
Table 3-3: ini File Parameters for Cu
stomizing Product Name
Parameter Description
UseProductName
Defines whether or not to change the product name:
[0] = Don’t change the product name (default).
[1] = Enable product name change.
UserProductName
The text string that replaces the product name.
The default is ‘MediaPack’.
The string can be up to 29 characters.
