Version 5.8 139 September 2009
SIP User's Manual 3. Web-Based Management
3.3.4.8.5 Configuring the Internal SRV Table
The 'Internal SRV Table' page provides a table for resolving host names to DNS A-
Records. Three different A-Records can be assigned to each host name. Each A-Record
contains the host name, priority, weight, and port.
Notes:
• If the Internal SRV table is configured, the device initially attempts to
resolve a domain name using this table. If the domain name isn't found,
the device performs an Service Record (SRV) resolution using an
external DNS server.
• You can also configure the Internal SRV table using the ini file table
parameter SRV2IP (refer to ''DNS Parameters'' on page 223).
¾ To configure the Internal SRV table:
1. Open the 'Internal SRV Table' page (Configuration tab > Protocol Configuration
menu > Routing Tables submenu > Internal SRV Table page item).
Figure 3-80: Internal SRV Table Page
2. In the 'Domain Name' field, enter the host name to be translated. You can enter a
string of up to 31 characters long.
3. From the 'Transport Type' drop-down list, select a transport type.
4. In the 'DNS Name 1' field, enter the first DNS A-Record to which the host name is
translated.
5. In the 'Priority', 'Weight' and 'Port' fields, enter the relevant values
6. Repeat steps 4 through 5, for the second and third DNS names, if required.
7. Repeat steps 2 through 6, for each entry.
8. Click the Submit button to save your changes.
9. To save the changes so they are available after a hardware reset or power fail, refer to
''Saving Configuration'' on page 167.
