SIP User's Manual 166 Document #: LTRT-65412
MP-11x & MP-124
3. Under the 'Reset Configuration' group, from the 'Graceful Option' drop-down list, select
one of the following options:
• 'Yes': Reset starts only after the user-defined time in the 'Shutdown Timeout' field
(refer to Step 4) expires or after no more active traffic exists (the earliest thereof).
In addition, no new traffic is accepted.
• 'No': Reset starts regardless of traffic, and any existing traffic is terminated at
once.
4. In the 'Shutdown Timeout' field (relevant only if the 'Graceful Option' in the previous
step is set to 'Yes'), enter the time after which the device resets. Note that if no traffic
exists and the time has not yet expired, the device resets.
5. Click the Reset button; a confirmation message box appears, requesting you to
confirm.
Figure 3-100: Reset Confirmation Message Box
6. Click OK to confirm device reset; if the parameter 'Graceful Option' is set to 'Yes' (in
Step 3), the reset is delayed and a screen displaying the number of remaining calls
and time is displayed. When the device begins to reset, a message appears notifying
you of this.
Notes:
• Throughout the Web interface, parameters preceded by the lightning
symbol are not applied on-the-fly and require that you reset the device for
them to take effect.
• When you modify parameters that require a device reset, once you click
the Submit button in the relevant page, the toolbar displays the word
"Reset" (refer to ''Toolbar'' on page 29) to indicate that a device reset is
required.
