Version 5.8 197 September 2009
SIP User's Manual 5. Element Management System (EMS)
3. Type cf set, and then press Enter; the following prompt is displayed:
Enter data below. Type a period (.) on an empty line to
finish.
The configuration session is now active and all data entered at the terminal is parsed
as configuration text (formatted as an ini file).
4. Type the following at the configuration session:
[ IPSEC_IKEDB_TABLE ]
FORMAT IKE_DB_INDEX = IkePolicySharedKey;
IPSEC_IKEDB_TABLE 0 = <IKE_password>;
[ \IPSEC_IKEDB_TABLE ]
[ IPSEC_SPD_TABLE ]
FORMAT SPD_INDEX = IpsecPolicyRemoteIpAddress,
IpsecPolicyLocalIpAddresstype;
IPSEC_SPD_TABLE 0 = <IP Address>,0;
[ \IPSEC_SPD_TABLE ]
EnableIPSec = 1
where:
• <IKE_password> is the password for the initial IKE pre-shared key.
• <IP Address> is the IP address of the EMS server used for connecting to the
device for which IPSec connectivity is established.
5. To end the PuTTY configuration session, type a full-stop (“.”) on an empty line; the
device responds with the following:
INI File replaced
6. To save the configuration to the non-volatile memory, type sar; the device reboots with
IPSec enabled.
Note: If you have enabled IPSec and you want to change the IP address and/or IKE
password, you need to first disable IPSec. Perform the procedure as above,
but omit the lines IPSEC_IKEDB_TABLE 0 and IPSEC_SPD_TABLE 0, and
set EnableIPSec to 0. Once you have done this, repeat the exact procedure
as described above, but with the new IP address and/or password.
