Version 5.8 421 September 2009
SIP User's Manual 9. IP Telephony Capabilities
Field Name Description
SrcPhoneNum
Source Phone Number
SrcNumBeforeMap
Source Number Before Manipulation
TON
Destination Phone Number Type
NPI
Destination Phone Number Plan
DstPhoneNum
Destination Phone Number
DstNumBeforeMap
Destination Number Before Manipulation
Durat
Call Duration
Coder
Selected Coder
Intrv
Packet Interval
RtpIp
RTP IP Address
Port
Remote RTP Port
TrmSd
Initiator of Call Release (IP, Tel, Unknown)
TrmReason
Termination Reason
Fax
Fax Transaction during the Call
InPackets
Number of Incoming Packets
OutPackets
Number of Outgoing Packets
PackLoss
Local Packet Loss
RemotePackLoss
Number of Outgoing Lost Packets
UniqueId
unique RTP ID
SetupTime
Call Setup Time
ConnectTime
Call Connect Time
ReleaseTime
Call Release Time
RTPdelay
RTP Delay
RTPjitter
RTP Jitter
RTPssrc
Local RTP SSRC
RemoteRTPssrc
Remote RTP SSRC
RedirectReason
Redirect Reason
TON
Redirection Phone Number Type
MeteringPulses
Number of Generated Metering Pulses
NPI
Redirection Phone Number Plan
RedirectPhonNum
Redirection Phone Number
