AudioCodes MP-124 User Manual

SIP User's Manual 478 Document #: LTRT-65412
MP-11x & MP-124
Function Specification
Physical
Dimensions (HxWxD)
42 mm (1.65 in.) x 172 mm (6.8 in.) x 220 mm (8.7 in.)
Weight
0.5 kg (Approx.)
Environmental
 Operational: 5 to 40°C (41 to 104°F)
 Storage: -25 to 70°C (-77 to 158°F)
 Humidity: 10 to 90% non-condensing
Mounting
Desktop, 19-inch rack, and wall mounting
Note: The rack mount is a special order option.
Power
100-240 VAC Nominal 50/60 Hz
Management
Configuration
HTTP-based Embedded Web Server (Web browser) or ini file
Management and
Maintenance
 SNMP v2c; SNMP v3
 Syslog according to RFC 3164
 Local RS-232 terminal
 Web Management via HTTP or HTTPS
 Telnet
Type Approvals
Safety and EMC
UL 60950-1, FCC part 15 Class B
CE Mark EN 60950-1, EN 55022, EN 55024, EN61000-3-2, EN61000-3-3,
EN55024.

AudioCodes MP-124 Specifications

General

Model	MP-124
Category	Gateway
Analog Ports	24 FXS
Ethernet Ports	2
Protocol Support	SIP, H.323
Fax Support	T.38, G.711 pass-through
Power Supply	100-240VAC, 50-60Hz
Operating Temperature	0°C to 40°C
Voice Codecs	G.711, G.729, G.723.1, G.726
Management	SNMP
Storage Temperature	-20°C to 70°C
Humidity	10% to 90%, non-condensing
Network Interface	10/100Base-T Ethernet
