Version 5.8 67 September 2009
SIP User's Manual 3. Web-Based Management
Parameter Description
The address of the host / network you want to reach is determined by an AND operation that is
applied to the fields 'Destination IP Address' and 'Destination Mask'. For example, to reach the
network 10.8.x.x, enter 10.8.0.0 in the field 'Destination IP Address' and 255.255.0.0 in the field
'Destination Mask'. As a result of the AND operation, the value of the last two octets in the field
'Destination IP Address' is ignored.
To reach a specific host, enter its IP address in the field 'Destination IP Address' and 255.255.255.255
in the field 'Destination Mask'.
Gateway IP Address
[RoutingTableGatewaysColumn]
The IP address of the router (next hop) to which the
packets are sent if their destination matches the rules
in the adjacent columns.
Note: The Gateway address must be in the same
subnet on which the address is configured on the
'Multiple Interface Table' page (refer to ''Configuring the
Multiple Interface Table'' on page 58).
Metric
[RoutingTableHopsCountColumn]
The maximum number of times a packet can be
forwarded (hops) between the device and destination
(typically, up to 20).
Note: This parameter must be set to a number greater
than 0 for the routing rule to be valid. Routing entries
with Hop Count equals 0 are local routes set
automatically by the device.
Interface
[RoutingTableInterfacesColumn]
Specifies the interface (network type) to which the
routing rule is applied.
[0] = OAMP (default).
[1] = Media.
[2] = Control.
For detailed information on the network types, refer to
''Configuring the Multiple Interface Table'' on page 58.
