Version 5.8 95 September 2009
SIP User's Manual 3. Web-Based Management
2. Configure the parameters as required.
3. Click the Submit button to save your changes, or click the Register or Un-Register
buttons to save your changes and register / unregister to a Proxy / Registrar.
4. To save the changes to flash memory, refer to ''Saving Configuration'' on page 167.
Click the Prox
y Set Table
button to open the 'Proxy Sets Table' page to configure
groups of proxy addresses. Alternatively, you can open this page from the Proxy Sets
Table page item (refer to ''Configuring the Proxy Sets Table'' on page 95 for a descri
ption of
this page).
3.3.4.3.2 Configuring the Proxy Sets Table
The 'Proxy Sets Table' page allows you to define Proxy Sets. A Proxy Set is a group of
Proxy servers defined by IP address or fully qualified domain name (FQDN). You can
define up to six Proxy Sets, each having a unique ID number and each containing up to five
Proxy server addresses. For each Proxy server address, you can define the transport type
(i.e., UDP, TCP, or TLS). In addition, Proxy load balancing and redundancy mechanisms
can be applied per Proxy Set (if a Proxy Set contains more than one Proxy address).
Proxy Sets can later be assigned to IP Groups of type SERVER only (refer to ''Configuring
the IP Groups'' on page 99). Wh
en the device sends an INVITE message to an IP Group, it
is sent to the IP address/domain name defined for the Proxy Set that is associated with the
specific IP Group. In other words, the Proxy Set represents the destination of the call.
Notes:
• You can also configure the Proxy Sets table using two complementary ini
file table parameters (refer to ''SIP Configuration Parameters'' on page
252):
- ProxyIP: used for creating a Proxy Set ID defined with IP addresses.
- ProxySet: used for defining various attributes per Proxy Set ID.
• Proxy Sets can be assigned only to SERVER-type IP Groups.
