PAGE 116
Operation via Display and Keypad
Switch from Audio mixer presets
The system allows to store three different Audio mixer presets wherein all le-
vel adjustments and activation status of all Audio interfaces are saved.
During a connection you can switch between the saved Audio mixer presets
by pressing the phone button .
Display connection parameters
If the
Status
key (
1
) is pressed during a connection, the Audio transmission
parameters are displayed in detail.
Pressing it a second time the parameters of an optionally configurated data
transfer, that is possible parallel to the Audio transfer, are displayed.
Display system information
If no connection exists, you can display the following information by pressing
the phone button :
– system name (see Page 70, Configuration
→
MAGIC DC7/AC1 XIP
→
System Settings
→
General
→
System Name)
– Adjusted or by DHCP assigned IP address
– In the LAN/SIP mode, whether the registration had been successful or not
Particularly, when multiple units are used at one station, systems are easy to
identify. In combination with the optional MAGIC DC7/AC1 XIP LAN soft-
ware (order number 430260, see Page 133) this name is displayed in the equip-
ment list.
