7.6 Category: CounterAndTimerControl
This chapter lists all features that relates to control and monitoring of Counters and Tim-
ers.
7.6.1 CounterDuration
Sets the duration (or number of events) before the CounterEnd event is generated.
When the counter reaches the CounterDuration value, a CounterEnd event is generated,
the CounterActive signal becomes inactive and the counter stops counting until a new
trigger happens or it is explicitly reset with CounterReset.
Name CounterDuration
Category CounterAndTimerControl
Interface IInteger
Access Read / Write
Unit -
Values 0 ... 65535 (Increment: 1)
7.6.2 CounterEventActivation
Selects the Activation mode Event Source signal.
Name CounterEventActivation
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
RisingEdge Counts on the Rising Edge of the signal.
FallingEdge Counts on the Falling Edge of the signal.
AnyEdge
Counts on the Falling or rising Edge of the selected sig-
nal.
