7.11.1.2 VCXU
Notice
On the VCXU-15M, VCXU-90M, VCXU-123M, binning is calculated in the sensor. In
contrast to binning in the FPGA, the binning in the sensor increases the frame rate.
Camera Type BinningSelector
[Region0]
BinningSelector
[Sensor]
Monochrome
VCXU-02M
1 ... 2 1 ... 1
VCXU-04M 1 ... 2 1 ... 1
VCXU-13M
1 ... 2 1 ... 1
VCXU-15M
1 ... 2 1 ... 2
*
VCXU-22M.R 1 ... 2 1 ... 1
VCXU-23M 1 ... 2 1 ... 1
VCXU-24M 1 ... 2 1 ... 1
VCXU-25M 1 ... 2 1 ... 1
VCXU-31M 1 ... 2 1 ... 1
VCXU-32M 1 ... 2 1 ... 1
VCXU-50M 1 ... 2 1 ... 1
VCXU-50MP
1 ... 2 1 ... 1
VCXU-51M 1 ... 2 1 ... 1
VCXU-53M 1 ... 2 1 ... 1
VCXU-65M.R 1 ... 2 1 ... 1
VCXU-90M 1 ... 2 1 ... 2
*
VCXU-91M 1 ... 2 1 ... 1
VCXU-123M 1 ... 2 1 ... 2
*
VCXU-124M 1 ... 2 1 ... 1
VCXU-125M.R 1 ... 2 1 ... 1
VCXU-201M.R 1 ... 2 1 ... 1
Color
VCXU-02C 1 ... 2 1 ... 1
VCXU-04C 1 ... 2 1 ... 1
VCXU-13C
1 ... 2 1 ... 1
VCXU-15C
1 ... 2 1 ... 1
VCXU-22C.R 1 ... 2 1 ... 1
VCXU-23C
1 ... 2 1 ... 1
VCXU-24C 1 ... 2 1 ... 1
VCXU-25C 1 ... 2 1 ... 1
VCXU-31C 1 ... 2 1 ... 1
VCXU-32C 1 ... 2 1 ... 1
VCXU-50C 1 ... 2 1 ... 1
VCXU-51C 1 ... 2 1 ... 1
VCXU-53C 1 ... 2 1 ... 1
VCXU-65C.R 1 ... 2 1 ... 1
VCXU-90C 1 ... 2 1 ... 1
VCXU-91C 1 ... 2 1 ... 1
VCXU-123C 1 ... 2 1 ... 1
VCXU-124C 1 ... 2 1 ... 1
VCXU-125C.R 1 ... 2 1 ... 1
VCXU-201C.R 1 ... 2
1 ... 1
*)
BinningVertical is also switched to 2
