7.11.6.1 CalibrationAngleOfPolarizationO󰀨set
Adds a calibration o󰀨set to compensate for an individual "roll" angle of the camera, intro-
duced by mounting tolerances. The o󰀨set is added to all type of output data that incorpo-
rates an angle, like false color representation and angle of polarization data. The o󰀨set is
without e󰀨ect to raw data and to degree of linear polarization data.
Name CalibrationAngleOfPolarizationO󰀨set
Category
ImageFormatControl → CalibrationControl
Interface IFloat
Access Read / Write
Unit °
Values -180 ... 179.9 (Increment: 0.1)
7.11.6.2 CalibrationEnable
Activates the calibration of the four polarized light channels by applying matrix calcula-
tions and an angle o󰀨set.
Name CalibrationEnable
Category
ImageFormatControl → CalibrationControl
Interface IBoolean
Access Read / Write
Unit -
Values
true = 1 (On)
false = 0 (O󰀨)
7.11.6.3 CalibrationMatrixValue
Represents the value of the selected gain factor inside the calibration matrix.
Name CalibrationMatrixValue
Category
ImageFormatControl → CalibrationControl
Interface IFloat
Access Read / Write
Unit -
Values -8 ... 7.99999999627470970154 (Increment: 0.00001)
