7.9.9 LinePWMMaxDuration (only VCXG.I / .XT / .PTP)
Sets the maximum possible LinePWMDuration time in μs. This value is specied by the
connected lighting.
Name LinePWMMaxDuration
Category DigitalIOControl
Interface IInteger
Access Read / Write
Unit µs
Values 1 - 50000 (Increment: 1)
7.9.10 LinePWMMaxDutyCycle (only VCXG.I / .XT / .PTP)
Sets the maximum possible LinePWMDutyCycle in %. This value is specied by the con-
nected illumination.
Name LinePWMMaxDutyCycle
Category DigitalIOControl
Interface IInteger
Access Read / Write
Unit %
Values 1 - 100 (Increment: 1)
7.9.11 LinePWMMode (only VCXG.I / .XT / .PTP)
Selects the PWM mode of the selected output line.
Name LinePWMMode
Category DigitalIOControl
Interface IEnumeration
Access Read / Write
Unit -
Values
Fixed
Frequency
The selected output line generate a xed frequency of puls-
es starting with every transition from 0 to 1 and stopping
with every transition from 1 to 0.
O󰀨
The PWM Mode is o󰀨. The output line acts as a normal
output.
OnePulse
The selected output line generate one pulse with every
transition from 0 to 1.
