7.3.19 TriggerMode
Controls if the selected trigger is active.
Name TriggerMode
Category AcqusitionControl
Interface IEnumeration
Access Read / Write
Unit -
Values
O󰀨 Disables the selected trigger.
On Enable the selected trigger.
VCXG / VCXU (only cameras with rolling shutter sensors)
The sensor TriggerMode depends on the SensorShutterMode.
Camera Type
(Sensor)
Trigger Mode = On
TriggerMode=O󰀨
Monochrome / Color
Shutter Mode Readout Mode Shutter Mode Readout Mode
VCXG-22M.R
VCXG-22C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXU-22M.R
VCXU-22C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXG-65M.R
VCXG-65C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXU-65M.R
VCXU-65C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXG-201M.R (.I)
VCXG-201C.R (.I)
Global Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXG-125M.R
VCXG-125C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXU-125M.R
VCXU-125C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
VCXU-201M.R
VCXU-201C.R
Global Reset Non-overlapped Global Reset Non-overlapped
Rolling Non-overlapped Rolling Overlapped
7.3.19.1 Timings of the image transmission VCXG
Trigger Mode
The transfer of the rst image starts after data for a complete packet size is stored in
camera's TX memory. All further images start the transfer immediately after the rst one
is completed, if the camera works in burst mode with a high frame rate and the sensor
acquires images faster than the interface can transfer. These additional pictures are not
referenced to the time of the readout. If the sensor is triggered slowly enough, each image
will behave like the rst image.
Freerun Mode
The transfer of each image starts after data for a complete packet size is stored in the
camera's TX memory. Since the sensor delivers more data than the interface can man-
age, depending on set ROI, images are repeatedly discarded and not transferred. There-
fore, gaps of di󰀨erent sizes can be created via the GigE interface.
